Locate jammed paper

No.

Paper jam locations

Automatic document feeder (ADF)

Door C

Door D

Multi-purpose paper feeder

3000-sheet large-capacity tray

2x 500-sheet tray

Stapler

• Booklet Finisher

• Hole Punch and Stapler Finisher
