Cleaning Jammed Paper

Paper jam in the automatic document feeder (ADF)

1. Remove all original documents from the ADF tray.

2. Open the door B.

3. Remove the jammed paper.

Note:

• Make sure that all paper fragments are removed.

4. Close the cover.

5. Open the door B1.
