Pantum P2500 Series Maintenance Manual

3–2
3.1 Components Summary
The following diagram shows the summary of the composition.
Low-voltage power supply module
High
-voltage
power
supply
module
RAM module
Data control module
External devices
Operating module
(Control Panel)
Engine control module
Imaging system
Laser unit
Motor driver module
Paper Tray
Output
module
Fixing unit
Transfer
Charging
Cleaning
Exposure
Develeping
USB/NET/WiFi
Interface module
Paper feed system

Pantum P2500 Series Specifications

General

Print Technology	Monochrome Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	15, 000 pages
Input Capacity	150 sheets
Output Capacity	100 sheets
Connectivity	USB 2.0
Dimensions	337 x 220 x 178 mm
Processor Speed	600 MHz
Memory	128 MB
Print Speed	22 ppm (A4)
First Print Out Time	Less than 7.8s
Operating System Support	Windows, Mac, Linux
Media Sizes	A4, A5, A6, Letter, Legal, Executive
Media Types	Plain, Thick, Cardstock, Label, Envelope, Thin
Media Weight	60 - 163 g/m²
