Pantum P2500 Series Maintenance Manual

6–4
6.3 Error Code
Code
Cause
Solution
NO.000
The main motor is faulty
1. Make sure that the main motor cable is
connected correctly if the cable
connection is faulty.
2. Replace the main motor if it is faulty;
3. Replace the high voltage power board
if it is faulty.
NO.001
The LSU line
synchronizing signal is
abnormal
1. Replace the laser if there is a fault in
the LSU laser motor;
2. Replace the high voltage power board
if there is a fault in its LSU laser motor
control gear.
3. Make sure that the motor cable is
connected correctly if the motor cable
connection is faulty.
4. Replace the high voltage power board
if it is faulty
NO.002
A fault is detected in the
LSU motor
N0.003-012
1. Check the fuser component cable, and
make sure the cable is properly
connected.
2. Replace the fuser component if it is
faulty;
3. Replace the high voltage power board
if it is faulty;

Pantum P2500 Series Specifications

General

Print Technology	Monochrome Laser
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	15, 000 pages
Input Capacity	150 sheets
Output Capacity	100 sheets
Connectivity	USB 2.0
Dimensions	337 x 220 x 178 mm
Processor Speed	600 MHz
Memory	128 MB
Print Speed	22 ppm (A4)
First Print Out Time	Less than 7.8s
Operating System Support	Windows, Mac, Linux
Media Sizes	A4, A5, A6, Letter, Legal, Executive
Media Types	Plain, Thick, Cardstock, Label, Envelope, Thin
Media Weight	60 - 163 g/m²
