4-10
2.
U
nscrew the four re
taining screws.
3.
R
emove the engine
board.
Note:
•
After remov
ing the engine board, there
will be four conduc
t
ive cyl
inders. Please put these
in a safe place to avoi
d losing them
.
•
Ensure the conduc
tive cyli
nders stay in place during the
installation,
as
one o
f
them is
an
OPC
and
differ
ent
from the othe
r cylinders
.
