Digiplex LED Keypads 17
5.0 PGM PROGRAMMING
5.1 PGM STATE
Section 005: Option [1]
The keypad's on-board PGM can be set as normally open or
normally closed. When an open PGM is activated, it will close the
circuit from ground and enable any devices connected to it. When
a closed PGM is activated, it will open the circuit and disable any
devices connected to it. When the PGM Activation Event occurs
(see section 5.2 of this manual), the PGM will switch to its
opposite state (i.e. open to closed or closed to open). The PGM
can provide 50mA to any device connected to it.
Option [5] OFF = PGM is Normally Open (default)
Option [5] ON = PGM is Normally Closed
5.2 PGM ACTIVATION EVENT
Section 007
The PGM Activation Event determines which event(s)
will activate the keypad's on-board PGM. (For details
on the available activation events, refer to the PGM
Programming Table in the Digiplex Programming
Guide)
Use the PGM Table to program a PGM Activation Event by
following these steps:
