Paradox Digiplex V2.14 User Manual

12
PROGRAMMING GUIDE
Programmable Outputs
Please note that options [1] through [5] in section [502] represent PGMs 1 to 5 respectively. The control panel deactivates
an activated PGM one of two ways:
Option OFF = Follow Activation Event:
If the first digit of the PGM Activation Event is set at 1, 2, 3, 4, or 7, the PGM will remain activated until the PGM Activation
Event has ended. It will ignore the PGM Deactivation Event. If the first digit of the PGM Activation Event is set at 8, 9, A, B, C,
D, E, or F, the PGM will remain activated until the PGM Deactivation Event occurs.
Option ON = Follow PGM Delay Timer:
After activating the PGM, the control panel will start the PGM delay timer and the PGM will deactivate only when the PGM
delay timer has elapsed regardless of the PGM Deactivation Event.
NOTE1*:
0 = Occurs in all partitions enabled in the sytstem (see section [500]).
1 = Partition 1 3 = Partition 3
2 = Partition 2 4 = Partition 4
8 = Occurs in at least one partition enabled in the system.
Section PGM Event Group
(First Digit)
Event Group
(Second Digit)
Event Selection
(on/off)
[400] PGM1 Activation Event ___ ___ 1 2 3 4 5 6 7 8
[401] PGM1 Deactivation Event ___ ___ 1 2 3 4 5 6 7 8
[402] PGM2 Activation Event ___ ___ 1 2 3 4 5 6 7 8
[403] PGM2 Deactivation Event ___ ___ 1 2 3 4 5 6 7 8
[404] PGM3 Activation Event ___ ___ 1 2 3 4 5 6 7 8
[405] PGM3 Deactivation Event ___ ___ 1 2 3 4 5 6 7 8
[406] PGM4 Activation Event ___ ___ 1 2 3 4 5 6 7 8
[407] PGM4 Deactivation Event ___ ___ 1 2 3 4 5 6 7 8
[408] PGM5 Activation Event ___ ___ 1 2 3 4 5 6 7 8
[409] PGM5 Deactivation Event ___ ___ 1 2 3 4 5 6 7 8
Feature Select Programming
First
Digit
Event
Second
Digit
1 2 3 4 5 6 7 8
0
PGM Disabled
N/A N/A N/A N/A N/A N/A N/A N/A N/A
1
Status 1
Note1*
Regular
Armed
Force
Armed
Stay
Armed
Instant
Armed
Strobe
(until alarm
cancelled)
Silent
Alarm
(until cancel
alarm/bell cut-off)
Audible
Alarm
(until cancel
alarm/bell cut-off)
Fire Alarm
(until alarm
cancelled or
bell cut-off)
2
Status 2
Note1*
Ready
Status
Exit Delay
Entry Delay
Trouble Alarm
Memory
Zones
Bypassed
(armed/not)
User or
Installer
Programming
Keypad
Lockout
3
Status 3
Note1*
Intellizone
Delay
Fire Delay Auto Arm Access Tamper Zone Low
Battery
Fire Loop Zone
Supervision
