PROGRAMMING GUIDE
CONTACT ID REPORT CODE LIST
If using the Ademco Contact ID format, key in the 2-digit hexadecimal value (PROG. VALUE) to program the desired report
codes into sections [600] to [718].
CID# Reporting Prog.
Code Value
CID# Reporting Prog.
Code Value
CID# Reporting Prog.
Code Value
MEDICAL ALARMS - 100 204 Low Water Level 2F 403 Automatic O/C 5D
100 Medical Alarm 01 205 Pump Activated 30 404 Late to O/C 5E
101 Pendant Transmitter 02 206 Pump Failure 31 405 Deferred 5F
102 Fail to Report In 03 SYSTEM TROUBLES - 300 & 310 406 Cancel 60
FIRE ALARMS - 110 300 System Trouble 32 407 Remote Arm/Disarm 61
110 Fire Alarm 04 301 AC Loss 33 408 Quick Arm 62
111 Smoke 05 302 Low System Battery 34 409 Keyswitch O/C 63
112 Combustion 06 303 RAM Checksum Bad 35 REMOTE ACCESS - 410
113 Water Flow 07 304 ROM Checksum Bad 36 411 Callback Request Made 64
114 Heat 08 305 System Reset 37 412 Success - Download Access 65
115 Pull Station 09 306 Panel Program Changed 38 413 Unsuccessful Access 66
116 Duct 0A 307 Self-Test Failure 39 414 System Shutdown 67
117 Flame 0B 308 System Shutdown 3A 415 Dialer Shutdown 68
118 Near Alarm 0C 309 Battery Test Failure 3B ACCESS CONTROL - 420
PANIC ALARMS - 120 310 Ground Fault 3C 421 Access Denied 69
120 Panic Alarm 0D SOUNDER/RELAY TROUBLES - 320 422 Access Report By User 6A
121 Duress 0E 320 Sounder Relay 3D SOUNDER RELAY DISABLES - 520
122 Silent 0F 321 Bell 1 3E 520 Sounder/Relay Disabled 6B
123 Audible 10 322 Bell 2 3F 521 Bell 1 Disable 6C
BURGLAR ALARMS - 130 323 Alarm Relay 40 522 Bell 2 Disable 6D
130 Burglary 11 324 Trouble Relay 41 523 Alarm Relay Disable 6E
131 Perimeter 12 325 Reversing 42 524 Trouble Relay Disable 6F
132 Interior 13 SYSTEM PERIPHERAL TROUBLES - 330 & 340 525 Reversing Relay Disable 70
133 24-Hour 14 330 System Peripheral 43 COMMUNICATION DISABLES - 550 & 560
134 Entry/Exit 15 331 Polling Loop Open 44 551 Dialer Disabled 71
135 Day/Night 16 332 Polling Loop Short 45 552 Radio xmitter Disabled 72
136 Outdoor 17 333 Exp. Module Failure 46 BYPASSES - 570
137 Tamper 18 334 Repeater Failure 47 570 Zone Bypass 73
138 Near Alarm 19 335 Local Printer Paper Out 48 571 Fire Bypass 74
GENERAL ALARMS - 140 336 Local Printer Failure 49 572 24-Hour Zone Bypass 75
140 General Alarm 1A COMMUNICATION TROUBLES - 350 & 360 573 Burg. Bypass 76
141 Polling Loop Open 1B 350 Communication 4A 574 Group Bypass 77
142 Polling Loop Short 1C 351 Telco Fault 1 4B TEST/MISC. - 600
143 Expansion Module Failure 1D 352 Telco Fault 2 4C 601 Manual Trigger Test 78
144 Sensor Tamper 1E 353 Long Range Radio 4D 602 Periodic Test Report 79
145 Expansion Module Tamper 1F 354 Fail to Communicate 4E 603 Periodic RF Xmission 7A
24-HOUR NON-BURGLARY - 150 & 160 355 Loss of Radio Supervision 4F 604 Fire Test 7B
150 24-Hour Non-Burglary 20 356 Loss of Central Polling 50 605 Status Report to Follow 7C
151 Gas Detected 21 PROTECTION LOOP TROUBLES - 370 606 Listen-in to Follow 7D
152 Refrigeration 22 370 Protection Loop 51 607 Walk Test Mode 7E
153 Loss of Heat 23 371 Protection Loop Open 52 621 Event Log Reset 7F
154 Water Leakage 24 372 Protection Loop short 53 622 Event Log 50% Full 80
155 Foil Break 25 373 Fire Trouble 54 623 Event Log 90% Full 81
156 Day Trouble 26 SENSOR TROUBLES - 380 624 Event Log Overflow 82
157 Low Bottled Gas Level 27 380 Sensor Trouble 55 625 Time/Date Reset 83
158 High Temp 28 381 Loss of Super. -RF 56 626 Time/Date Inaccurate 84
159 Low Temp 29 382 Loss of Super. - RPM 57 627 Program Mode Entry 85
161 Loss of Air Flow 2A 383 Sensor Tamper 58 628 Program Mode Exit 86
FIRE SUPERVISORY - 200 & 210 384 RF xmtr. Low Battery 59 631 Exception Schedule Change 87
200 Fire Supervisory 2B OPEN/CLOSE - 400
201 Low Water Pressure 2C 400 Open/Close 5A
202 Low CO2 2D 401 O/C by User 5B
203 Gate Valve Sensor 2E 402 Group O/C 5C
