Esprit Keypads 15
trouble conditions are taking place and/or are in
memory. Only the troubles that are relevant to you are
listed below. If a trouble appears and it is not listed
below, call your monitoring station to come service
your system.
Trouble conditions will remain in memory. Pressing
on the [2
ND] key displays current trouble conditions.
Pressing [
CLEAR] will erase trouble conditions in
memory.
Key [1] - No battery/low battery
If battery is not connected to the control panel, or if it
is at low capacity, key [1] illuminates. This means that
the battery connected to the panel should be replaced
because it can no longer provide adequate back-up
current in the event of a power failure.
Key [3] - AC power failure
If AC power is not being supplied to the control panel,
key [3] will illuminate. AC trouble can be excluded
from keypad “trouble display” by your alarm installer.
Key [4] - Bell disconnect
If a bell or siren is not connected to the bell/siren
output, this is indicated by the illumination of key [4]
in trouble display mode.
Key [8] - Timer loss
Your alarm system’s clock must be reprogrammed.
This is the only trouble we recommend that you
correct.
K6X6-EU12.fm Page 15 Tuesday, June 27, 2006 11:05 AM
