10 Reference & Installation Manual
The serial number is located on Grafica’s PCB or enter
section [0000] in Step 3 to view Grafica’s version and serial
number.
3.2 PROGRAMMING METHODS
The following methods can be used when programming the Grafica
keypad:
3.2.1 FEATURE SELECT PROGRAMMING
You can program sections by enabling or disabling options.
Within these sections, keys [1] to [8] or scroll keys represent a
specific Grafica option. Use the scroll keys to highlight the
desired option and press the corresponding action key to
enable or disable the option. An “X” will appear to indicate that
the option is enabled. Press the appropriate action key to save
the status of selected option(s).
3.2.2 DECIMAL PROGRAMMING
Some sections require the entry of a decimal value. For this
method, any value from 000 to 255 can be entered.
3.2.3 HEXADECIMAL PROGRAMMING
Some sections require the entry of a hexadecimal values [A]
to [F]. Press the “#” key to scroll through these values. If the
value is left unchanged for a second or two, Grafica will
automatically select it, and move forward to the next digit.
