10 Programming Guide
Zone Programming
For keypad zone programming, see page 16.
Zone Definitions Stay Arm Sleep Arm Fully Arm Zone Definitions
01 = Entry Delay 1 Entry Delay 1 Entry Delay 1 Entry Delay 1 11 = Instant Fire†
02 = Entry Delay 2 Entry Delay 2 Entry Delay 2 Entry Delay 2 12 = Delayed Fire†
03 = Entry Delay 1 (Full Arm) Not Armed Not Armed Entry Delay 1 13 = Instant Fire Silent†
04 = Entry Delay2 (Full Arm)
Not Armed Not Armed Entry Delay 2 14 = Delayed Fire Silent†
05 = Follow Follow* Follow* Follow* 15 = 24Hr. Buzzer
06 = Follow (Sleep/Full Arm) Not Armed Follow* Follow 16 = 24Hr. Burglary
07 = Follow (Full Arm)
Not Armed Not Armed Follow 17 = 24Hr. Hold-up
08 = Instant Instant* Instant* Instant* 18 = 24Hr. Gas
09 = Instant (Sleep/Full Arm) Not Armed Instant* Instant 19 = 24Hr. Heat
10 = Instant (Full Arm)
Not Armed Not Armed Instant 20 = 24Hr. Water
21 = 24Hr. Freeze
22 = 24hr. Panic
23 = Instant No Pre-Alarm
* Flex-Instant = Zone will follow the delay at section [720], (default is 15 seconds / 0 = instant zone) 24 = Follow No Pre-Alarm
** On-board hardwire control panel zones only 25 = Keyswitch Maintain**
† APR-ZX8 inputs do not support fire zones.
For 2-wire smoke installations (not supported by SP5500), these definitions apply to Zone 1 Input
only. Section [705], option [3] must be enabled.
For 4-wire smoke installations, use any panel on-board zone input.
26 = Keyswitch Momentary**
Keyswitch Options (25-26)
[1]- N/A
[2]- N/A
[3]- N/A
[4] OFF = Disarm
ON = Disarm only if Stay/
Sleep armed
[5] = Arm only
[6] = Stay arming*
[7] = Sleep arming*
[8] = N/A
* Select only one. If all are off,
keyswitch will regular arm.
Partition Assignment
[1]- Partition 1
[2]- Partition 2
[3]- Both partitions
Zone Options
[1] = Auto-zone Shutdown
[2] = Bypassable Zone
[3] = RF Supervision
[4] [5]
OFF OFF Audible Alarm
OFF ON Pulsed Alarm
ON OFF Silent Alarm
ON ON Report Only
[6] = Intellizone
[7] = Delay alarm transmission
[8] = Force Zone
To Next Page
