16 Programming Guide
Keypad Programming
Keypad Zone Number Assignment
Entry Point Zone Assignment (StayD)
Step Action Details
1 [ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash. [MAINTENANCE CODE] may also be used.
2
Press and hold (3sec)
[ARM] + [STAY] = on
3 [ZONE NUMBER] + [ENTER]* MG32LED/MG32LCD= 2 digits: 01 to 32
MG10LEDV/H = 1 digit: 1 to 0(10)
* To erase a keypad zone number, press [CLEAR], then [ENTER].
Step Action Details
1 [ENTER] + [INSTALLER CODE]
(default: 0000 / 000000)
[ARM] + [STAY] = flash.
2 Press and hold [OFF] (3sec) [ARM] + [STAY] = on
3 [ZONE NUMBER]* MG32LED/MG32LCD = 2 digits: 01 to 32
MG10LEDV/H = 1 digit: 1 to 0(10)
* The first zone you program will be the designated entry point and will flash. Up to three
more path zones can be added; these zones will light up and stay lit.
4 [ENTER] Press [ENTER] to save and exit
