Paradox SPECTRA SP5500 User Manual

6 Programming Guide
System Overview
Wireless Keypad Planning
When deleting a wireless keypad (MG32LRF) from the system, the corresponding StayD path zones will also be deleted.
Module Description
Maximum num-
ber per system
Current
Consumption
MG32LRF 32-Zone Wireless LED Keypad Module 8 Min. = 44mA / Max. = 72mA
MG10LEDV/H,
MG32LED,
MG32LCD
10 and 32-Zone Hardwired LED Keypad Module
15 total including
APR-ZX8
MG10LED: Min. = 44mA / Max. = 72mA
MG32LED: Min. = 49mA / Max. = 148mA
MG32LCD: Min. = 43mA / Max. = 86mA
APR-ZX8 8-Zone Expansion Module 3 Min. =29mA / Max. = 31mA
MG-RPT1 Magellan Wireless Repeater Module 2 Average =57mA
VDMP3 Plug-In Voice Dialer 1 Min. = 28mA / Max. = 28mA
IP100 Internet Module 1 Min. = 90mA / Max. = 120mA
MG-RTX3 Wireless Expansion Module (Spectra SP only) 1 Min. = 61mA / Max. = 143mA
Serial # Sticker Description
Path Zone
(Entry Point)
Path Zone Path Zone Path Zone
MG32LRF 1
MG32LRF 2
MG32LRF 3
MG32LRF 4
MG32LRF 5
MG32LRF 6
MG32LRF 7
MG32LRF 8

Paradox SPECTRA SP5500 Specifications

General

Partitions	2
User Codes	32
Event Buffer	256 events
StayD Mode	Yes
Communication	GSM (optional)
Remote Control	Yes
System Type	Hybrid
Wireless Zones	32
Battery Backup	12V 7Ah
Operating Temperature	0°C to 50°C (32°F to 122°F)
Humidity	5% to 90% non-condensing
