Magellan / Spectra SP 3
Installer Quick Menu
Zones
Keypad Zone Number Assignment (Keypad Programming)
Delays
Time and Date
Step Action Details
1
+ [
INSTALLER CODE] = flash. Programmed zones are lit (button or LED depending on keypad).
[MAINTENANCE CODE] may also be used.
2 [ZONE NUMBER] MG32LRF/MG32LED/MG32LCD =2 digits: 01 to 32
MG10LEDV/H = 1 digit: 1 to 0(10)
3 [ENROLL OR ERASE ZONE] Wireless zone = open/close cover or press learn/tamper switch. Hardwired zone = Press
[ENTER]. To erase a programmed zone, press [SLEEP] for 3 seconds.
4 [ZONE TYPE] Refer to Zone Programming on page 10 for the zone type (zone definition).
5 ASSIGN PARTITION
[1] and/or [2] + [
ENTER]
Assign the zone to one or both partitions and press [
ENTER]. By default, all zones are
assigned to partition 1. Goes to next available zone.
Notes Partition 2 status LEDs, display the signal strength of the selected wireless zone
(4 LEDs = best signal; 1 LED = weak signal; No LEDs = hardwired panel/keypad zone)
Step Action Details
1 [ENTER] + [INSTALLER CODE] [ARM] + [STAY] = flash. [MAINTENANCE CODE] may also be used.
2
Press and hold (3sec)
[ARM] + [STAY] = on.
3 [ZONE NUMBER] + [ENTER]* MG32LED/MG32LCD = 2 digits: 01 to 32
MG10LEDV/H = 1 digit: 1 to 0(10)
* To erase a keypad zone number, press [
CLEAR], then [ENTER].
Step Action Details
1
+ [
INSTALLER CODE] = flash. [MAINTENANCE CODE] may also be used.
2
3 [1] = Entry Delay 1 (sec.)
[2] = Entry Delay 2 (sec.)
[3] = Exit Delay (sec.)
[4] = Bell Cut-Off (min.)
4 [000] to [255] Entry/Exit Delay = seconds / Bell Cut-Off = minutes / 000 = default value
Step Action Details
1
+ [
INSTALLER CODE] = flash. [MAINTENANCE CODE] may also be used.
2
+ [5]
4 [HH:MM] Enter time. If HH = 13 or more, skip to step 6.
5 [TIME FORMAT] Enter time format ([1] = 24hr; [2] = AM; [3] = PM).
6 [YYYY/MM/DD] Enter date.
To Next Page
