D-11
Programming
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
ANALOG OUTPUT
SETUP::INPUTS & OUTPUTS::ANALOG OUTPUT
The analog output blocks converts the demand percentage into a form suitable for driving the analog output electronics of the
Drive.
Range: -300.00 to 300.00 %
The demanded value to output.
e: See below
The output hardware Voltage type. An incorrect selection will force the VALUE to be set to zero.
0 : -10..+10 V
Functional Description
The Drive has two analog outputs. There is an ANALOG OUTPUT function block associated with each of these:
AOUT1 is associated with terminal X12/06
AOUT2 is associated with terminal X12/07
