Parker ac890 User Manual

10-1 Keypad Menus
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
Chapter 10
Keypad Menus
This chapter details the Keypad menus available on the 6511 and 6901 Keypads when used on the
890CS Common Bus Supply and the 890CD Common Bus Drive & 890SD Standalone Drive.
The 6511 keypad displays a numbered menu, whilst the 6901 ke
ypad displays information using
concise text and allows access to more parameters.
♦ Menus for the 890CS Common Bus Supply
DIAGNOSTIC menu
♦ Menus for the
890 Common Bus/Standalone Drive
OPERATOR menu
DIAGNOSTIC menu
QUICK SETUP menu
SETUP menu
SYSTEM menu
