Programming D-26
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
DRIVE CONFIG
SETUP::DRIVE SETUP::DRIVE CONFIG
This block contains general drive set-up parameters and also determines what hardware can be plugged in the A, B and F slots.
These parameters must be set correctly in order for the drive to run correctly.
Parameter Descriptions
DRIVE NAME
PREF: 136.01
Default: 890 DRIVE
Range:
Enter a user name for the drive.
CONTROL MODE
PREF: 136.0
2
Default: 0
Range: See below
This parameter defines how the drive will control the motor. If PMAC control is required, the motor wizard feature in the 890
DSE
Configuration Tool MUST be used to correctly set-up the motor and feedback device parameters. Failure to do so may
result in damage to the servo motor.
Enumerated Value : CONTROL MODE
0 : VOLTS / Hz
1 : SENSORLESS VEC
2 : CLOSED-LOOP VEC
3 : 4-Q REGEN
4 : PMAC Used to control Permanent-Magnet AC brushless motors.
SUPPLY VOLTAGE
PREF: 136.19
Default: 380V to 460V
Range: See below
Changes the dynamic braking threshold on expected supply voltage range.
Enumerated Value : Supply Voltage
0 : 230V
1 : 380V to 480V
2 : 500V
3 : 575V
4 : 690V
