D-169 Programming
890CS Common Bus Supply - Frames B & D; 890CD Common Bus Drive and 890SD Standalone Drive - Frames B, C & D
Parameter Descriptions
Enumerated Value : Source
0 : V MASTER POSN
1 : FBK ENCR SHAFT
2 : FBK ENCR LOAD
3 : REF ENCR SHAFT
4 : REF ENCR LOAD
ENCODER LINES
PREF:160.02
Default:1024
Range: 4 to 65536
Sets the number of lines of the simulated encoder.
DIRECTION
PREF:160.03
Default: SAME AS SOURCE
Range:See below
Allows inverting the synthetic encoder direction with regards to the source direction.
Enumerated Value : Direction
0 : SAME AS SOURCE
1 : REVERSE OF SRCE
Z PULSE OFFSET
PREF:160.05
Default:0.000 deg.
Range: 0.0000 to 360.000
deg.
Sets the position in degrees at which the marker pulse (Z pulse) occurs.
