Miscellaneous Inputs (P4098) Flag number
Drive Fault Input 0 64
Drive Fault Input 1 65
Drive Fault Input 2 66
Drive Fault Input 3 67
Drive Fault Input 4 68
Drive Fault Input 5 69
Drive Fault Input 6 70
Drive Fault Input 7 71
Opto-Isolated High Speed Input INP72 72
Opto-Isolated High Speed Input INP73 73
Opto-Isolated High Speed Input INP74 74
Opto-Isolated High Speed Input INP75 75
Opto-Isolated High Speed Input INP76 76
Opto-Isolated High Speed Input INP77 77
Opto-Isolated High Speed Input INP78 78
Opto-Isolated High Speed Input INP79 79
Miscellaneous Outputs (P4099) Flag number
LED 4 Green 96
LED 4 Red 97
LED 5 Green 98
LED 5 Red 99
LED 6 Green 100
LED 6 Red 101
LED 7 Red 102
LED 7 Red 103
Appendix D Drive I/O 125
