MSG30-5524-M1/UK
26
Parker Hannifin
Pump & Motor Division Europe
Trollhättan, Sweden
Service/Spare Parts Manual
F10-056
Pos Part No Description Qty Remarks
Housing parts
61 3724205 Hex Socket Plug M12*1 1 VSTI12X1EDVITCF
110 3798203 Barrel Housing Assy Type F 1
110 3798204 Barrel Housing Assy Type S 1
130 Hex Socket Plug for S housing 1 8 HP5ON-S
130 Hex Socket Plug for F housing 1 VSTI18X1,5EDVITCF
211 3780330 Bearing Housing Type C 1 Require item 61
211 3799967 Bearing Housing Type I 1 Require item 61
211 3780130 Bearing Housing Type S 1 Require item 61
231 3796201 Seal Carrier 1
Rotating parts
310 3799455 Shaft type C 1
310 3799457 Shaft type D 1
310 3799451 Shaft type K 1 Require flat key
310 3799453 Shaft type S 1
310 3799459 Shaft type T 1 Require flat key
321 3724451** Flat Key for K shaft 1
321 3724438** Flat Key for T shaft 1
430 3724474*** Barrel Support 1
452 3791589 Ring Gear 1
For other parts please contact Parker Hannifin
Seal kits
3793495* Sealing kit type V FPM
Repair Spare part Kit
3724226 Type A (Motor)
3724227 Type L (CCW pump)
3724228 Type R (CW pump)
Bearing spare part kit
3723972 Bearing kit
Shim kit
3721331 Shims kit
* The kit contain 1 pcs O-ring for F10-80,
**Kit contain 100 pcs, ***Kit contain 20 pcs
Seal kit contain:
O-rings pos: 221, 225, 229
Shaft seal pos: 233
Retaining rings pos: 237, 238
Repair spare part kit
contain:
Valve plate pos: 121
Cylinder Barrel pos: 411
Pistons pos: 440 (7 pcs)
Hex Screws pos: 491 (4 pcs)
Bearing spare part kit
contain:
Tap Rol Bearing pos: 460, 470
Spacer pos: 476
Retaining rings pos: 478
Shim kit contain:
Shims pos: 488
(1 pcs on each side)
Spare Parts F10-056
