27
Parker Hannifin
Pump & Motor Division Europe
Trollhättan, Sweden
Service/Spare Parts ManualMSG30-5524-M1/UK
Spare Parts F10-080
F10-080
Pos Part No Description Qty Remarks
Housing parts
61 Hex Socket Plug M12*1 1 VSTI12X1EDVITCF
110 3722721 Barrel Housing Assy Type F 1
110 3722723 Barrel Housing Assy Type S 1
130 Hex Socket Plug S housing 1 10 HP5ON-S
130 Hex Socket Plug F housing 1 VSTI22X1.5EDVITCF
211 3780331 Bearing Housing Type C 1 Require item 61
211 3780127 Bearing Housing Type I 1 Require item 61
211 3780124 Bearing Housing Type S 1 Require item 61
231 3796201 Seal Carrier 1
Rotating parts
310 3799686 Shaft type C 1
310 3799688 Shaft type D 1
310 3799682 Shaft type K 1 Require flat key
310 3799684 Shaft type S 1
310 3799690 Shaft type T 1 Require flat key
321 3724445** Flat Key for K shaft 1
321 3724438** Flat Key for T shaft 1
430 3724478*** Barrel Support 1
452 3799822 Ring Gear 1
For other parts please contact Parker Hannifin
Seal kits
3793495* Sealing kit type V FPM
Repair Spare part Kit
3724229 Type A (Motor)
3724230 Type L (CCW pump)
3724231 Type R (CW pump)
Bearing spare part kit
3723973 Bearing kit
Shim kit
3721332 Shims kit
* The kit contain 1 pcs O-ring for F10-56
**Kit contain 100 pcs, ***Kit contain 20 pcs
Seal kit contain:
O-rings pos: 221, 225, 229
Shaft seal pos: 233
Retaining rings pos: 237, 238
Repair spare part kit
contain:
Valve plate pos: 121
Cylinder Barrel pos: 411
Pistons pos: 440 (7 pcs)
Hex Screws pos: 491 (4 pcs)
Bearing spare part kit
contain:
Tap Rol Bearing pos: 460, 470
Spacer pos: 476
Retaining rings pos: 478
Shim kit contain:
Shims pos: 488
(1 pcs on each side)
