MSG30-5524-M1/UK
30
Parker Hannifin
Pump & Motor Division Europe
Trollhättan, Sweden
Service/Spare Parts Manual
Spare Parts F10-125
F10-125
Pos Part No Description Qty Remarks
Housing parts
61 Hex Socket Plug M12*1 1 VSTI12X1EDVITCF
110 3709914 Barrel Housing Assy Type F 1
110 3794372 Barrel Housing Assy Type S 1
130 Hex Socket Plug S housing 1 12 HP5ON-S
130 Hex Socket Plug F housing 1 VSTI22X1.5EDVITCF
211 3781449 Bearing Housing Type C 1 Require item 61
211 3781447 Bearing Housing Type I 1 Require item 61
211 3781448 Bearing Housing Type S 1 Require item 61
231 3796182 Seal Carrier 1
Rotating parts
310 3783323 Shaft type C 1
310 3783322 Shaft type D 1
310 3783321 Shaft type K 1 Require flat key
310 3783320 Shaft type S 1
310 3783324 Shaft type T 1 Require flat key
321 3724446* Flat Key for K shaft 1
321 3724439* Flat Key for T shaft 1
430 3724476** Barrel Support 1
452 3783319 Ring Gear 1
For other parts please contact Parker Hannifin
Seal kits
3798092 Sealing kit type V FPM
Repair Spare part Kit
3724238 Type A (Motor)
3724239 Type L (CCW pump)
3724240 Type R (CW pump)
Bearing spare part kit
3723975 Bearing kit
Shim kit
3721334 Shims kit
*Kit contain 100 pcs, **Kit contain 20 pcs
Seal kit contain:
O-rings pos: 221, 225, 229
Shaft seal pos: 233
Retaining rings pos: 237, 238
Repair spare part kit
contain:
Valve plate pos: 121
Cylinder Barrel pos: 411
Pistons pos: 440 (7 pcs)
Hex Screws pos: 491 (4 pcs)
Bearing spare part kit
contain:
Tap Rol Bearing pos: 460, 470
Spacer pos: 476
Retaining rings pos: 478
Shim kit contain:
Shims pos: 488
(1 pcs on each side)
