Service/Spare Parts ManualMSG30-5524-M1/UK
Spare Parts
F10-037
Pos Part No Description Qty Remarks
Housing parts
61 Hex Socket Plug M12*1 1 VSTI12X1EDVITCF
110 3721864 Barrel Housing Assy Type F 1
110 3721863 Barrel Housing Assy Type S 1
130 Hex Socket Plug for S housing 1 8 HP5ON-S
130 Hex Socket Plug for F housing 1 VSTI18X1,5EDVITCF
211 3784481 Bearing Housing Type C 1 Require item 61
211 3788317 Bearing Housing Type I 1 Require item 61
211 3788323 Bearing Housing Type S 1 Require item 61
211 3788320 Bearing Housing Type T 1 Require item 61
231 3797194 Seal Carrier 1
Rotating parts
310 3799648 Shaft type C 1
310 3799638 Shaft type D 1
310 3799632 Shaft type K 1 Require flat key
310 3799644 Shaft type P 1 Require flat key
310 3799634 Shaft type S 1
310 3799640 Shaft type T 1 Require flat key
321 3724437* Flat Key for K and P shaft 1
321 3724449* Flat Key for T shaft 1
430 3724477** Barrel Support 1
452 3791927 Ring Gear 1
For other parts please contact Parker Hannifin
Seal kits
3793493 Sealing kit type V FPM
Repair Spare part Kit
3724223 Type A (Motor)
3724224 Type L (CCW pump)
3724225 Type R (CW pump)
Bearing spare part kit
3723971 Bearing kit
Shim kit
3721330 Shims kit
*Kit contain 100 pcs, **Kit contain 20 pcs
Seal kit contain:
O-rings pos: 221, 225, 229
Shaft seal pos: 233
Retaining rings pos: 237, 238
Repair spare part kit
contain:
Valve plate pos: 121
Cylinder Barrel pos: 411
Pistons pos: 440 (7 pcs)
Hex Screws pos: 491 (4 pcs)
Bearing spare part kit
contain:
Tap Rol Bearing pos: 460, 470
Spacer pos: 476
Retaining rings pos: 478
Shim kit contain:
Shims pos: 488
(1 pcs on each side)
