Appendix C - Order Matrix
Input
1 T/C or mV
2 Volts/mA
3 RTD
4 All Inputs
Output Group 1
Control Output 1
and/or Event
1 Relay
2 SSR Driver
3 4-20 mA & Relay
4 4-20 mA & SSR Driver
Output Group 2
Control Output 2
and/or Event
0 None
1 Relay
2 SSR Driver
3 4-20 mA
4 4-20 mA & Relay
5 4-20 mA & SSR Driver
Output Group 3
Alarm or Event
0 None
1 Relay
2 SSR Driver
Remote
0 None
1 Position Prop.*
2 Remote Run/Hold
3 RS-485 Std. Com.**
4 RS-485 Std. Com.***
5 RS-485 Total Access Com.**
6 RS-485 Total Access Com.***
Voltage
1 115VAC Input & Relays
2 230VAC Input & Relays
3 115VAC Input & 230VAC Relays
Option Suffix
(Blank) None
EO Extended Features Software Option
XP 24VDC Transmitter Power Supply
XA 24VDC Power Supply
* Output Group 2 cannot be 0 or 3.
** Cannot be included when Output Group 2 selections 3, 4, or 5.
***Cannot be included when Output Group 3 selection is 1 or 2.
