PAGE 71
Appendix D
Product Specifications
Measurement Error Limit • Type J, K, T, E, N, C, T/C's and RTD +/-.25% of reading
plus 1 degree @ 25 degrees C
• Type R, S, B T/C's +/- .25% of span @ 25 degrees C
• mA, mV and VDC +/- .25% of scaled span plus 1 Least
Significant Digit @ 25 degrees C
Ambient Temperature Error 0.01% of span per degree C deviation from 25 degrees C
Scan Rate 1 scan/second
Display Resolution 0 to 3 decimal places (depending upon input type
selected)
Noise Rejection Normal mode, 85 dB minimum at 60 Hz or greater.
Common mode, 90 dB minimum, 115 VAC maximum.
Line Voltage 115/230 VAC +/- 10% 50/60 Hz
Power Consumption 15VA maximum
Operating Temperature 0 to 55 degrees C
32 to 131 degrees F
Storage Temperature -40 to 65 degrees C
-40 to 149 degrees F
Humidity 0 to 90% RH, non condensing
Dimensions 1/4 DIN front panel (96mm x 96mm) and 5.8 inches deep
Weight 3 pounds maximum
Vibration 0.5 to 100 Hz @ 0.5g
Agency Approvals UL and CSA
Warranty 3 years, see inside back page.
