PAGE 36
**All values except Profile Loop Count (PLCt) are initialized to zero and all event outputs are
initialized to OFF, with the exception of the first profile. Profile Loop Count (PLCt) is set to 1.
The first profile has the number of segments initialized to zero, to turn the profile OFF, but the
profile has values stored in it for demonstration purposes. By setting the number of segments
to two, the profile can be reviewed and/or executed.
PROFILE 1 VALUES FOR DEMONSTRATION PURPOSES
Code Value
rt .10 Ramp Time
SP 100 Setpoint
E1 on Event 1 on
E2 oFF Event 2 off
E3 oFF Event 3 off
St .10 Soak Time
E1 oFF Event 1 off
E2 on Event 2 on
E3 oFF Event 3 off
rt .10 Ramp Time
SP 0 Setpoint
E1 oFF Event 1 off
E2 oFF Event 2 off
E3 on Event 3 on
St .10 Soak Time
E1 oFF Event 1 off
E2 oFF Event 2 off
E3 oFF Event 3 off
PLct 1 Profile Loop Count
dhru 0 Deviation Hold after Ramp Up - None
dhrd 0 Deviation Hold after Ramp Down - None
PEnd 0 Profile End Control - Abort - oFF Mode
TABLE 3-4 ENABLE MODE CONFIGURATION PROCEDURE
To enter the Enable mode, press and hold the UP and DOWN keys while in CtrL or oFF
modes. All the display lamps will light. After 10 seconds, the lamps will go out and EnAb will
be displayed. Release the keys and the display will change to EtSt. Press and release the
DOWN key and each mode to be enabled/disabled will be displayed. With the Enable mode
prompt for the desired mode displayed, press the SCROLL key to verify that the displayed
mode is either on (enabled) or oFF (disabled). Press the DOWN key to turn off the mode,
press the UP key to turn on the mode or press the SCROLL key to advance the display to the
next Enable mode prompt. Use the "Your Setting" column in the table to record your program-
ming.
A Hardware jumper located on the Controller Board (See Appendix A-2, page 64) can be used
to lock/unlock the Enable mode. When the jumper is moved to the locked position, entry into
the Enable mode is not possible until the jumper is moved to the unlock position.
1 Test Mode EtSt on or oFF
oFF
2 Calibration Mode ECAL on or oFF
oFF
DISPLAY AVAILABLE FACTORY YOUR
STEP DESCRIPTION CODE SETTINGS SETTING SETTING
