PAGE 72
THERMOCOUPLE
TYPE RANGE TYPE RANGE
J -130 to 760°C E 0 to 750°C
-200 to 1400°F 0 to 1400°F
K -130 to 1370°C B 200 to 1800°C
-200 to 2500°F 400 to 3300°F
T -200 to 400°C N 0 to 1300°C
-330 to 750°F 0 to 2370°F
R 200 to 1650°C C 200 to 2300°C
400 to 3000°F 390 to 4170°F
S 200 to 1650°C
400 to 3000°F
RTD VOLTS MILLIVOLTS
100 OHM 0 to 5VDC 0 to 25mVDC
-140 to 440°C 1 to 5VDC 0 to 50mVDC
-220 to 750°F 10 to 50mVDC
0 to 25mVDC
MILLIAMPS
4-20mA input is accommodated via
10-50mV or 1-5V with the addition
of the appropriate external shunt resistor
SENSOR FAULT DETECTION
Displays Hi or Lo process input for thermocouple or RTD inputs (10% above or below range)
and sensor break, SnSr. On/Off outputs and events go off, proportional outputs go to 0%
output. Sensor fault detection is not functional for 0 to 5 VDC.
CONTROL ADJUSTMENTS
On/Off Hysteresis 0 to 300 units
Proportional Band 1 to 3000 units
Manual Reset -1500 to 1500 units
Auto Reset 0.0 to 100 repeats/min.
Rate 0.0 to 10.0 min.
Cycle Time 1 to 240 sec.
Position Proportioning 0.0 to 50.0%
Sensitivity
First Output Position -1000 to 1000 units
Spread -1000 to 1000 units
(Second Output Position)
