PAGE 80
The following is a sample profile intended to assist in understanding how the profile controller
functions. Be sure to disconnect all control outputs before running this profile.
Press and release the SCROLL key until Prog appears on the display then press the DOWN
key. Press and release the DOWN key until diSp appears then press the SCROLL key. Press
and hold the UP key until the display shows a 5 then press the SCROLL key. Press and
release the Down key until Ptb appears then press the SCROLL key. Press and hold the UP
key until a 3 appears then press the SCROLL key. Press the UP key and Prog will appear.
Press and release the SCROLL key until PEnt appears then press the DOWN key. Perform
the following keystrokes:
Display Keystroke
Pn SCROLL
X DOWN
1 SCROLL
nS SCROLL
X UP
6 SCROLL
rt SCROLL
X UP/DOWN
0.10 SCROLL
SP SCROLL
X UP/Down
100 SCROLL
St SCROLL
X UP/DOWN
0.10 SCROLL
rt SCROLL
X UP/DOWN
0.10 SCROLL
SP SCROLL
X UP/DOWN
150 SCROLL
St SCROLL
X UP/DOWN
rt SCROLL
X UP/DOWN
0.10 SCROLL
SP SCROLL
X UP/DOWN
300 SCROLL
St SCROLL
X UP/DOWN
0.10 SCROLL
rt SCROLL
X UP/DOWN
0.10 SCROLL
SP SCROLL
X UP/DOWN
200 SCROLL
St SCROLL
X UP/DOWN
0.10 SCROLL
rt SCROLL
X UP/DOWN
0.10 SCROLL
SP SCROLL
X UP/DOWN
100 SCROLL
St SCROLL
X UP/DOWN
0.10 SCROLL
rt SCROLL
X UPDOWN
0.10 SCROLL
SP SCROLL
X UP/DOWN
50 SCROLL
St SCROLL
X UP/DOWN
0.10 SCROLL
PLct SCROLL
X UP/DOWN
2 SCROLL
dhru SCROLL
X UP/DOWN
0 SCROLL
dhrd SCROLL
X UP/DOWN
0 SCROLL
PEnd SCROLL
X UP/DOWN
0 SCROLL
Pn UP
PEnt
With PEnt on the display,
press and release the
SCROLL key until P 1
appears in the display then
press RUN/ HOLD key. The
display will show run, then
display the ramping setpoint
of the profile. This is to
demonstrate how the profile
controller functions.
Sample Profile
