Partner SP-850 - CHAPTER 5 REPLACING FIELD REPLACEABLE UNITS (Frus); Safety and Precautions

53
CHAPTER 5
REPLACING FIELD REPLACEABLE UNITS (FRUs)
This chapter provides instructions for replacing FRUs. The following topics are described.
• Safety and precautions on the page 53
• Before you begin on the page 54
• Replacing parts on the page 54
• HDD on the page 55
• IO Panel Cover on the page 56
• Stand Base Back Cover on the page 56
• Stand Base on the page 57
• Back Cover on the page 58
• Speaker on the page 59
• Power Button on the page 59
• COM4 port and PS/2 Port on the page 60
• I/O Shield on the page 60
• Memory on the page 61
• Battery on the page 61
• Mainboard on the page 62
• Panel Bracket on the page 62
• Touch Panel, Front Bezel, LCD Panel on the page 63
Only qualied personnel should perform repairs on the SP-850. Damage
due to unauthorized servicing is not covered by the warranty.
Safety and precautions
Computer components and electronic circuit boards can be damaged by discharges of static electricity.
Working on computers that are still connected to a power supply can be extremely dangerous. Follow these
guidelines to avoid damage to the computer or injury to yourself.
• Always disconnect the unit from the power outlet.
• Leave all components inside the static-proof packaging that they ship with until they are ready for
installation.
• After replacing optional devices, make sure all screws, springs, or other small parts are in place and
are not left loose inside the case. Metallic parts or metal akes can cause electrical shorts.
If the LCD breaks and uid gets onto your hands or into your eyes,
immediately wash with water and seek medical attention.
CAUTION
CAUTION
