DATASHEET
P8136
13
8. RACK MOUNTING
Mount the equipment on a rack using the screws (A) and washers (B) provided, as illustrated in the figure.
TECHNICAL SPECIFICATIONS P8136
Mains power 230 VCA - 50/60 HZ
Mains power absorption 23 W
External DC power supply 24V
DC power absorption 1 A
Size 422 x 88 x 167 mm
Size of packaging 522 x 155 x 292 mm
Weight (net) 3,9 Kg
Weight (packaged) 4,7 Kg
