Paso P8136 - Appendix: Settings and Controls

α
SOUND SYSTEM SPECIALIST
SECTION C | SYSTEM LIMITS |
APPENDIX
SECTION A | SETTINGS AND CONTROLS |
1. Controls and settings of the
Master unit
• Save/restore configuration
• General output volume of the music channel
• Selection of the source of sound and control of the input level
• Sending the selected music to the remote P8136’s
• Activation/de-activation of music in the single zones
• Chime
master (active for stations connected to the TO MASTER UNITS socket)
• Volume control of ‘speech’ source
• Adjustment of VOX activation threshold
• Setting the address of the P8136 Master Unit
2. Slave Functions
• Address of slave unit within the P8136 master unit
• Group
• SINGLE/DUAL mode
•
Local chime (active for stations connected to the TO LOCAL UNITS socket)
3. ACMG8136 message playing card
• Installing ACMG8136 card
4. ACIO8136 expansion card
4.1 General settings for Master and Slave ACIO8136’s
• Master/Slave mode
• Address
• Common negative of the optoinsulated input contacts
• Speech filter (Low Cut Filter)
• Audio input
• Power supply
4.2 Settings for local ACIO8136’s
• Operating mode of audio input section and contacts
• Operating mode section relay outputs
SECTION B | CONNECTIONS |
• Connections of music sources (1)
• Connection of sources to the VOX inputs (1)
• Connection of amplifiers / speaker units (2)
• Connection of microphone stations and ACIO8136 cards (3) (4)
• Connection between Master and Slave (5)
