Observe the minimum distance required in relation to the finished floor!
Fig. 17: Wall mounting (version LEFT)
2. Stick one of the supplied self-adhesive spacers D in each corner on the rear of the unit.
Fig. 18: Spacers mounting
3. Hook the FOCUS unit onto the fastening sheet by inserting the lugs B into the slots E in the lock seam at the
top of the rear cover.
Fig. 19: Hooking the unit into the fastening sheet
