38 User Guide EN CheckMate 3
Time Setting of current time (hh:mm:ss)
Date Setting of current date (using Date format) (
± 2 days)
Date format Setting of date format (DD/MM/YY or MM/DD/YY)
Decimal separator Select whether to use “,” or “.” as decimal separator
Printer header Select header text for printouts (ex. company name).
Supervisor pin code setup Setting up the pin code required for changing from User
access level to Supervisor access level.
(See "Access level" on page 43 for details).
Data log setup ...
Selecting Data log setup ... from the General setup menu will display a screen showing the
data logging parameters.
This is where you make all settings for logging of data.
As most of the parameters are self-explanatory only items requiring for further clarification
are described below:
Log to internal memory Select whether or not log data should be saved in the
internal memory of the device to be displayed and
printed from the Data log menu (see "Data log" on
page 36).
Yes Log data is saved internally and send to
COM-port/LAN-server.
No Log data is send only to COM-port/LAN-server.
Print each measurement Yes Printer will print a header and subsequently each
logged measurement will be printed
automatically line by line
No Function deactivated
Mark measurement as invalid Yes After each measurement performed in either
Auto spot or Manual spot mode you will be
asked if you want to mark measurement as
invalid.
No Function deactivated
13:46
08/17/06
Log alarms only No
Log interval 6 sec
Log to internal memory Yes
Print each measurement No
Mark measurement as invalid
Yes
Network logging setup
Network logging No
