PBI CheckMate 3 - Connectivity; Basic specifications

PBI-Dansensor A/S COPYRIGHT © PBI-300042-B 10/2010
CheckMate 3 EN User Guide 49
4. Technical Information
Technical specifications
Electrical connections
Mains 100-240V AC, 50-60 Hz
Power consumption Zirconia O
2
sensor: max 40W
Electrochemical O
2
sensor: max 30W
Mechanical data
Analyzer size 180 x 315 x 220 mm (H x W x D)
Analyzer weight 3,7 kg
Box of one analyzer 400 x 320 x 300 mm (H x W x D)
Box weight 5,8 kg
IP classification IP 20
D
H
W
