PBI-Dansensor A/S COPYRIGHT © PBI-300042-B 10/2010
CheckMate 3 EN User Guide 39
Network logging setup Network logging Select whether or not network logging is
required.
Server IP Set up an IP-address to be used for
collecting log data for each measurement
via LAN.
This requires for setting up of a Server
Port number as well.
Server Port See above.
If Server IP or Server Port or both are set to 0 the function is
deactivated and data will only be send to the COM-port.
Acknowledge Acknowledge byte can be used if a
“handshake”is required for each
measurement between device and server,
each to be set up to same value.
If value is set to 0 function is deactivated.
Function can be used together with the TCP Wedge or TCP
File from Taltech, TCP File from Fogsoft or a proprietary
setup TCP/IP server.
Data is send out in same format and setup as for the COM-
port.
Data out format Format Select between ASCII or UNICODE
Data out Select which parameters are required for the data output.
Selected data is always send to the device’s COM-port and if
a server has been set up in Network logging (see above)
data is send here as well.
When using RS-232 COM port setting must be: 57600,N,8,1
Serial data dump specification
Each measurement is on one line terminated with a Carriage Return + Line Feed characters
(ASCII 0x0D, 0x0A).
The line consists of data separated by semicolons (";"). Last parameter is also followed by a
semicolon.
In the "Data log setup...” (see side 38) it can be selected whether the output format should
be ASCII or UNICODE.
When set to ASCII some international characters might come out as wrong ASCII characters.
The table on the next page shows which data is presented and the order of the data.
