NMS044 Reference Manual System LED Indications A-1
Appendix A Additional System Information
In this module:
A.1 System LED Indications .......................................................................................................A-1
A.1.1 LED Indicators for SoundAdvisor™ Model 831C SLM
A.1.2 LED Indicators for RV50X Cellular Gateway
A.1.3 LED Indicators for Solar Charge Controllers
A.2 Shipping and Storage Requirements .................................................................................A-5
A.2.1 Shipping the System
A.2.2 Preparing the System for Long Term Storage
A.2.3 Removing Cables From the Case
A.3 Understanding 831C SLM Connections ..............................................................................A-7
A.4 Updating NMS044 for Modem Low Power .........................................................................A-8
A.4.1 Installing the Modem LP Cable
A.4.2 Upgrading 831C SLM Firmware
A.4.3 Enabling Modem Low Power
A.5 Configuring the Gateway for Larson Davis Instruments .................................................A-11
A.5.1 Logging In to ACEmanager
A.5.2 Configuring LD Settings Utilizing the Template File
A.5.3 Configuring LD Settings Without the Template File
A.1 System LED Indications
This section is a reference for LED indicators on the 831C, the cellular gateway, and the
solar charge controller.
In this section:
• A.1.1 LED Indicators for SoundAdvisor™ Model 831C SLM
• A.1.2 LED Indicators for RV50X Cellular Gateway
• A.1.3 LED Indicators for Solar Charge Controllers
A.1.1 LED Indicators for SoundAdvisor™ Model 831C SLM
The SoundAdvisor™ 831C has a multi-color back-lighted keypad, which provides the
following colored indications for power and measurement statuses.
A
