Size Model Shaft
Dia.
B C D
(ma
x
.)
D
(min.)
E
(max.)
E
(min.)
Best
Lateral
14 LD
(w/o ring)
1.94 8.06 8.06 0.009 0.008 0.017 0.013 0.063
14 MD 1.94 9.88 7.50 0.010 0.007 0.016 0.010 0.125
14 MF 1.50 Keyed Keyed 0.007 0.006 - - 0.015
14 MFAH 1.50 Keyed Keyed 0.007 0.006 - - 0.015
14 PL 1.50 Keyed Keyed 0.007 0.006 - - MIDDLE
15 LC 2.19 9.25 9.81 0.012 0.010 0.012 0.008 0.125
15 MA 2.19 9.81 - 0.012 0.010 0.015 0.011 0.125
16 HH 1.94 9.75 9.75 0.008 0.007 0.015 0.011 0.063
16 HXB 1.94 9.50 9.50 0.008 0.007 0.015 0.011 0.125
16 MC 1.94 9.75 9.75 0.008 0.007 0.018 0.012 0.063
16 MF 1.69 Keyed Keyed 0.007 0.006 - - 0.018
16 PL 1.50 Keyed Keyed 0.007 0.006 - - MIDDLE
18 HH 2.19 Keyed Keyed 0.012 0.010 0.019 0.012 0.063
18 HXB 1.94 8.38 8.38 0.008 0.007 0.015 0.011 0.063
18 MA 1.94 11.13 6.31 0.012 0.010 0.021 0.015 0.063
18 MF 1.94 Keyed Keyed 0.010 0.007 - - 0.018
18 MFAL - Keyed Keyed 0.010 0.007 - - 0.018
18 PL 1.50 Keyed Keyed 0.007 0.006 - - MIDDLE
20 HH 2.19 Keyed Keyed 0.013 0.010 0.019 0.015 0.063
20 HXB 2.19 10.56 10.56 0.013 0.010 0.018 0.014 0.063
20 MA 2.19 11.75 11.75 0.012 0.010 0.015 0.010 0.063
20 MF 1.69 Keyed Keyed 0.007 0.006 - - 0.020
20 MFAL 2.19 Keyed Keyed 0.013 0.010 - - 0.020
20 PL 1.50 Keyed Keyed 0.007 0.006 - - MIDDLE
24 HH 2.44 Keyed Keyed 0.013 0.010 0.019 0.015 0.031
24 HHOH 2.44 Keyed Keyed 0.013 0.010 - - 0.125
24 HXB 2.19 Keyed Keyed 0.013 0.010 0.019 0.015 0.125
24 HXC 2.19 Keyed Keyed 0.013 0.010 0.019 0.015 0.125
24 MA 2.44 Keyed Keyed 0.013 0.010 0.018 0.014 0.063
24 MF 2.44 Keyed Keyed 0.013 0.010 - - 0.020
24 MFH 2.44 Keyed Keyed 0.013 0.010 - - 0.020
24 PL 1.69 Keyed Keyed 0.007 0.006 - - MIDDLE
26 HH 2.94 Keyed Keyed 0.013 0.010 0.019 0.015 0.125
26 HHOH 2.94 Keyed Keyed 0.013 0.010 - - 0.031
26 HXB 2.94 Keyed Keyed 0.013 0.010 0.019 0.015 0.063
27 MA 2.94 Keyed Keyed 0.013 0.010 0.020 0.016 0.063
28 HXB 2.94 Keyed Keyed 0.013 0.010 0.021 0.017 0.031
30 HH 2.94 Keyed Keyed 0.013 0.010 0.022 0.018 0.125
30 HHOH 2.94 Keyed Keyed 0.013 0.010 - - 0.031
30 LA 2.69 Keyed Keyed 0.013 0.010 0.021 0.015 0.063
30 MF 1.69 Keyed Keyed 0.007 0.006 - - 0.026
30 MFAH 2.44 Keyed Keyed 0.013 0.010 - - 0.026
30 MFH - Keyed Keyed 0.013 0.010 - - 0.026
30 PL 2.19 Keyed Keyed 0.013 0.010 - - MIDDLE
32 HXB 3.69 Keyed Keyed 0.014 0.012 0.021 0.017 0.031
36 HH 3.69 Keyed Keyed 0.014 0.012 0.025 0.015 0.125
36 HHOH 3.69 Keyed Keyed 0.014 0.012 - - 0.031
36 HXB 3.94 Keyed Keyed 0.014 0.012 0.022 0.018 0.125
36 MA 3.69 Keyed Keyed 0.014 0.012 0.018 0.014 0.125
36 MF 3.44 Keyed Keyed 0.013 0.010 - - 0.029
36 MFH 3.44 Keyed Keyed 0.013 0.010 - - 0.029
36 PL 2.44 Keyed Keyed 0.013 0.010 - - MIDDLE
42 HH - Keyed Keyed 0.014 0.012 0.025 0.015 0.125
42 HXB 3.94 Keyed Keyed 0.014 0.012 0.022 0.018 0.125
42 MF 3.44 Keyed Keyed 0.013 0.010 - - 0.036
