42 MFH 3.44 Keyed Keyed 0.013 0.010 - - 0.036
Size Model Shaft
Dia.
B C D
(max.)
D
(min.)
E
(max.)
E
(min.)
Best
Lateral
42 PL 2.44 Keyed Keyed 0.013 0.010 - - MIDDLE
48 HH 3.94 Keyed Keyed 0.016 0.012 0.028 0.019 0.125
48 HHOH 3.94 Keyed Keyed 0.016 0.012 - - 0.047
48 HXB 3.94 Keyed Keyed 0.014 0.012 0.025 0.019 0.125
48 MF 3.44 Keyed Keyed 0.013 0.010 - - 0.042
48 PL 2.69 Keyed Keyed 0.013 0.010 - - MIDDLE
54 MF 3.94 Keyed Keyed 0.014 0.012 - - 0.048
54 PL 3.19 Keyed Keyed 0.013 0.010 - - MIDDLE
56 HH 4.25 Keyed Keyed - - - - 0.063
56 HHOH 4.25 Keyed Keyed 0.016 0.012 - - 0.047
60 PL 3.94 Keyed Keyed 0.014 0.012 - - MIDDLE
66 HH - Keyed Keyed - - - - 0.063
66 MF 4.94 Keyed Keyed 0.016 0.012 - - 0.054
