Pellas X S.Control User Manual

21
10. TECHNICAL DATA
Power
230V~; 50Hz;
Current consumed by controller
0,04 A
Maximum nominal current
6 (6) A
Controller’s level of protection
IP20
Outer temperature
0...50 C
Storage temperature
0...65 C
Relative humidity
5 - 85% without
condensation of
water steam
Measuring scope of sensors’
temperature CT4
0...100 C
Measuring scope of sensors’
temperature CT4-P
-35...40 C
Accuracy of measuring
temperature with sensors CT4
and CT4-P
2 C
Clamps
For network
and signal
Screw clamps, wire
profile up to 2,5mm
2
,
tighten moment
0,4Nm, isolation
lenght 7mm
protecting
Screw clamps, wire
profile up to 2,5mm
2
,
tighten moment
0,5Nm, isolation
lenght 6mm
Display
Graphic LCD
Dimensions
224x200x80 mm
Weigth
1,4 kg
Norms
PN-EN 60730-2-9
PN-EN 60730-1
Software class
A
Protection class
For installing to
devices class I
Level of contamination
2
wg PN-EN 60730-1
11. STORAGE AND TRANSPORT
CONDITIONS
The controller can not be exposed to
immediate effects of atmospheric conditions
i.e. rain or sunrays. Temperature of storage
and transport should be within scope -15…65
degrees C.
During transport the controller can not be
exposed to vibrations bigger than typical for
transport of boilers.
12. CONTROLLER INSTALLATION
12.1 ENVIRONMENTAL CONDITIONS
Due to fire risk it is forbidden to use the
controller in proximity of explosive gases or
dust. Moreover the controller can not be
used in conditions of water steam
condensation or be exposed to effects of
water.
12.2 INSTALLATION REQUIREMENTS
The controller should be installed by a
qualified and authorized installer, in
accordance with current norms and
regulations. The producer is not responsible
for damages caused by failing to observe
valid law and this user manual. The
controller is designed to be built-in. This
means that it is attached to flat and stable
part of a boiler or a wall. It can not be used
as a separate device. Leave free space at
each partition of the controller (save for
assembly partition) at least 50mm. Leave
free space allowing for setting wires without
bending them, at least 100mm from back
partition of the controller. Outer temperature
and assembly surface should be within scope
of 0 – 50 degrees C.
