TYING MACHINE FIXION 2
29_133084-G
1. Turn on the tying machine (on/off button (20), see
Section 5.1, “Tying machine on/off”).
2. Open the swivel dispenser (11) with the lock/unlock
button (10).
3. Manually remove the upper guide by hand (13).
4. Press and hold the trigger for 4 seconds to raise the
support roller (31).
5. Turn off the tying machine (start/stop button (20),
see Section 5.1, “Tying machine on/off”).
6. Use a flathead screwdriver to remove the support
roller (31) and replace it if necessary.
Important
Remove the support roller (31) carefully to avoid
damaging the bearing.
29
