10
1110
879 6 15 3
4 2
32_15_005A
3
2
1
TECHNICAL CHARACTERISTICS
Prunion
Cutting capacity up to 45 mm, depending on type of wood
Pruning shears power supply voltage 43.2 V
Average power 250 W
Battery life Depending on the use and type of battery
Weight of pruning shears 860 g
Total vibration values (triax vector sum)
determined in accordance with EN 60745.
(Uncertainty K=1.5 m/s²)
a
h
<2.5 m/s² max.
Noise value measured according to the standard EN 60745-1
Sound power level measured
(uncertainty of K=3 dB)
L
WA
= 81 dB maximum
Level of acoustic pressure at the work station
measured
(uncertainty of K=3 dB)
L
WA
= 70 dB maximum
TECHNICAL SPECIFICATIONS OF THE PRUNERS
DESCRIPTION OF CUTTING HEAD
1– Trigger
2– Blade shaft
3– Blade
4– Hook
5– Knurled adjustment washer
6– Clamping wheel
7– Locking blade
8– M6 CHC screws
9– Lock washers
10– Flanged pin
11– Guard
1– Trigger
2– Optical sensor
3– Tool indicator
