PRUNING SHEARS AND 150 BATTERY VINION & PRUNION
26_116772-H
3.2. DESCRIPTION OF CUTTING HEAD
1. Trigger
2. Blade shaft
3. Blade
4. Hook
5. Knurled adjustment washer
6. Locking blade
7. CHC M6 screw
8. Lock washer
9. Clamping wheel
10. Guard
11. Rod clevis
1. Trigger
2. Optical sensor
3. Tool indicator
3.3. TECHNICAL SPECIFICATIONS OF THE PRUNERS
3.3.1. VINION
Cutting capacity up to 35 mm, depending on type of wood
Pruning shears power supply voltage 43.2 V
Average power 180 W
Battery autonomy Depending on the use and type of battery
Weight of pruning shears 680 g
Total vibration values (triax vector sum) determined in accor-
dance with EN 62841-1 (uncertainty of K=1.5 m/s²)
a
h
= 2.5 m/s²
Noise value measured according to standard EN 62841-1
Acoustic power level measured (uncertainty of K=3 dB) L
WA
=80 dB MAX
Level of acoustic pressure measured at the work station
(uncertainty of K=3 dB)
L
pA
=70 dB MAX
13
