FLECK 7000XTR Service Manual • 3
JOB SPECIFICATION SHEET
NOTE: Some options may not be available depending on
valve model or other options chosen.
Circle and/or fill in the appropriate data for future reference.
1. System Type:
A. Meter Immediate
B. Time Clock Delayed
C. Volume Override Delayed
D. Volume Override Immediate
E. Meter Delayed Weekly Reserve
F. Meter Delayed Variable Reserve
G. Meter Delayed Fixed Reserve
2. Valve Type:
A. 7000XTR
C. Regenerant Flow:
A. Downflow
B. Filter
C. Downflow Fill First
4. Display Format:
A. U.S.
B. Metric (French Degrees, German Degrees, or PPM)
5. Unit Capacity:
__________Grains/French Degrees/German Degrees/PPM
6. Water Hardness:
__________Grains/French Degrees/German Degrees/PPM
7. Capacity Safety Factor:
A. Zero
B. __________%
8. Volume Override:__________(Gallons or M
3
)
9. Regeneration Day Override:
A. Off
B. Every__________Days
10. Regeneration Time:
A. Delayed__________AM/PM
B. __________Immediate
11. Regeneration Cycle:
A. Step #1 _ _ : _ _ : _ _
B. Step #2 _ _ : _ _ : _ _
C. Step #3 _ _ : _ _ : _ _
D. Step #4 _ _ : _ _ : _ _
E. Step #5 _ _ : _ _ : _ _
F. Step #6 _ _ : _ _ : _ _
12. Auxiliary Relay:
A. Enabled
a. Auxiliary Relay Start 1 _ _ : _ _ : _ _
b. Auxiliary Relay End 1 _ _ : _ _ : _ _
c. Auxiliary Relay Start 2 _ _ : _ _ : _ _
d. Auxiliary Relay End 2 _ _ : _ _ : _ _
B. Disabled
13. Chemical Pump:
A. Enabled
B. Disabled
14. CPO Aux Relay Volume:__________(Gallons or M
3
)
15. CPO Aux Relay: _ _ : _ _ : _ _
16. Flow Meter Size: 1.25-inch Turbine
17. Generic Flow Meter for Maximum Flow Rate:
Add__________Gallons every__________Pulses
