IntelliBrite Landscape Light Installation and User’s Guide
Important Notice: Attention Installer: This manual contains important
information about the installation, operation and safe use of this product.
This information should be given to the owner and/or operator of this
product. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL.
i
IMPORTANT SAFETY WARNINGS AND PRECAUTIONS
© 2010 Pentair Water Pool and Spa, Inc. All rights reserved.
1620 Hawkins Ave., Sanford, NC 27330 • (919) 566-8000
10951 West Los Angeles Ave., Moorpark, CA 93021 • (800) 553-5000
IntelliBrite
®
, IntelliTouch
®
, EasyTouch
®
, SAm
®
and Pentair Water Pool and Spa
®
are trademarks and/or
registered trademarks of Pentair Water Pool and Spa, Inc. and/or its affiliated companies in the United
States and/or other countries. Unless noted, names and brands of others that may be used in this
document are not used to indicate an affiliation or endorsement between the proprietors of these names
and brands and Pentair Water Pool and Spa, Inc. Those names and brands may be the trademarks or
registered trademarks of those parties or others. P/N 690034 Rev C - 9/9/2010
Notice: The IntelliBrite® outdoor landscape LED color-changing lights are for
outdoor use ONLY.
Before installing the IntelliBrite® landscape LED light, read and
follow all warning notices and instructions which are included.
Failure to follow safety warnings and instructions can result in severe injury,
death, or property damage. Call (800) 831-7133 for additional free copies of
these instructions.
TRANSFORMER CONNECTION: Connecting the high
voltage side of the outdoor IntelliBrite LED landscape light
transformer to an IntelliTouch® or EasyTouch® control system must be installed
by a qualified electrician, according to the National Electrical Code (including
article 680-22) or Canadian Electrical Code (including section 68) and local
codes and ordinances. The electrician should also consult the local building
department regarding local codes.
• Do not exceed the maximum ratings of individual
components, wiring devices, and current carrying capacity
of conductors (see page 7).
• The LED landscape lighting supply circuit must be
protected by a Ground Fault Circuit Interrupter (GFCI) of
the CLASS A type with an appropriately rated circuit
breaker.
RISK OF ELECTRIC SHOCK! INSTALL ALL LUMINAIRES
TEN (10) Feet (3.05 Meters) OR MORE FROM THE POOL,
SPA, OR FOUNTAIN.
THE PENTAIR WATER POOL AND SPA INTELLIBRITE
OUTDOOR LANDSCAPE LIGHT LOW VOLTAGE CABLE SHALL:
A) BE PROTECTED BY ROUTING IN CLOSE PROXIMITY TO THE LUMINAIRE
OR FITTING, OR NEXT TO A BUILDING STRUCTURE SUCH AS A HOUSE OR
DECK; B) NOT BE BURIED EXCEPT FOR A MAXIMUM OF SIX (6) INCHES
(15.2 CM) IN ORDER TO CONNECT TO THE MAIN LOW VOLTAGE CABLE;
AND C) HAVE THE LENGTH CUT OFF SO THAT IT IS CONNECTED TO A
CONNECTOR WITHIN SIX (6) IN (15.2 CM) FROM A BUILDING STRUCTURE,
A LUMINAIRE, OR FITTING.
