Pentair intellidrive pid20 User Manual

Programming 13
Table 5 - Main Menu and Parameters
Menu
Settings
Parameter
Unit of
Measure
Value
Description
Default Min. Max.
Time/Date
Hour Format Hours 12Hr 12Hr 24Hr Selects 12 or 24 hour time scale.
Time HH:MM 1:00AM 1 24
Sets current time. Used for time
stamp in fault log.
Date MM/DD/YYYY 1/1/12 – –
Sets current date. Used for date
stamp in fault log.
PID Control
Proportional
Gain
– 1500 0 10000
Sets the PID controller gain. Used
in conjunction with all PID Control
parameters to control how fast or
slow the Drive reacts to pressure
changes.
Integration
Time
Milliseconds 500 ms 20 ms
65000
ms
Sets the PID controller integration
time. Used in conjunction with all
PID Control parameters to control
how fast or slow Drive reacts to
pressure changes.
Derivation
Time
Milliseconds 60 ms 0 ms
10000
ms
Sets PID controller derivation time.
Used in conjunction with all PID
Control parameters to control how
fast or slow Drive reacts to pressure
changes.
Derivative
Limit
– 120 0 2000
Sets derivative filter time constant
for PID controller.
Sleep
Boost
Differential
PSI 3 PSI 3 PSI 10 PSI
First part of Boost Process. Pressure
boost that happens before it goes to
Wake Delay.
BoostDelay MM:SS 1Min 30 Sec 5Min
The time Drive takes to start Boost
Process after system has stabilized.
Wake Up
Differential
PSI 5 PSI 5 PSI 15 PSI
Pressure amount below setpoint that
wakes up Drive.
Wake Delay MM:SS 15 Sec 3 Sec 2Min
Second part of the Boost Process.
The time it takes to ramp down
pressure during the Boost Process.
Password
Password Time
Out
HH:MM 1 Hr 1Min 6 Hr
Amount of time it takes to lock
keypad (after last button is pressed).
Password – 7777 0000 9999
Password used to unlock keypad.
Table 5 lists all available commands and parameters for the PENTEKINTELLIDRIVE.
