OPERATING THE PUMP 13/25
Manual
Assigns a speed to one of the four (4) programm buttons on the control panel. This mode can
only be used for programs 1-4. Programs 1 and 2 are manual by default.
To operate in manual mode, press one of the four program buttons and then press the start/
stop button. The pump will run the assigned speed or flow to that program button.
Egg timer
Programs 1-4 can be programmed to run at a certain speed or flow and for a duration of time
once a program button is pressed.
Programs 3 and 4 are egg timers by default. If you desire a different method of operation,
programs 3 and 4 can be changed to manual mode in the control menu.
To operate in egg time mode, press a program button and then press start/stop. The pump
will run that setting for the set amount of time and then turn off.
Schedule
Programs 1-8 start and stop at a specific time during a 24 hour period. Speeds or flows
programmed in schedule mode will override any manually selected speed or flow once the
next schedule command begins.
SET SPEEDS IN MANUAL MODE PROGRAMS 14 ONLY
1. Press menu.
2. Use up or down arrows to scroll to “Program 1-8”, then press select.
3. Use up or down arrows to find the program (1-4) you wish to edit, then press select.
4. “Operation mode” will display. Press select and use the up or down arrow to scroll to
“manual”. Press save.
5. Use the up or down arrow to scroll to “set type”. Press select and use the up or down
arrow to choose between “speed” or “flow”. Press save.
6. Use the up or down arrow to scroll to “Set speed/flow”. Press select and use the up or
down arrow to adjust the speed or flow settings.
7. Press save to save the new speed or flow setting.
24
