User Guide Riversoft
Ref. MKT-UG-045 / A - 13.03.2020 9 / 132
EN
Valve configuration
Injector ............................................................. E........................... G .......................... F........................... H
DLFC................................................................. 6 gpm................... 8 gpm................... 7 gpm................... 9 gpm
BLFC................................................................. 0.14 gpm.............. 0.14 gpm.............. 0.14 gpm.............. 0.14 gpm
Cycles duration [min]
Estimated water consumption per regeneration [L]
Softener connections
Inlet/Outlet ....................................................... ¾" BSPT, male
Drain line .......................................................... ½"
Overflow drain line ........................................... ½"
Electrical
Controller Operating Voltage ........................... 12 VAC (requires use of Pentair Water supplied transformer)
Input Supply Frequency ................................... 50 or 60 Hz
Motor Input Voltage.......................................... 12 VAC
Controller Power Consumption ....................... 6 W average
Protection rating .............................................. IP23
Transient overvoltages..................................... within the limits of category II
Pollution Degree .............................................. 3
Temporary overvoltages must be limited in duration and in frequency.
Softener Riversoft 15 Riversoft 30
Corresponding salt dosage (g/L of resin) 80 120 200 80 120 200
Salt amount per regen (kg) 1.2 1.8 3.0 2.4 3.6 6
Capacity (kg as CaCO
3
) to program (override preprogrammed
capacity)
0.6 0.75 0.93 1.21 1.49 1.86
Capacity in m
3
(for 300ppm inlet hardness and 100ppm residual
hardness)
3.02 3.74 4.67 6.03 7.45 9.31
Estimated salt consumption per year (kg) for 200 L daily water
consumption per person and 300 mg/L as CaCO
3
inlet hardness,
residual 100 mg/L as CaCO
3
45.8 -
61
55.5 -
74
74.1 -
98.8
86.6 -
115.5
105.1 -
140.1
145.9 -
233.5
Riversoft 4 Riversoft 8 Riversoft 15 Riversoft 30
C1 1 1 1 1 1 1 3 3 3 3 3 3
C2 27 28 30 29 31 34 52 56 63 59 66 81
C3 3 3 3 3 3 3 3 3 3 3 3 3
C4 1 1 1 1 1 1 3 3 3 3 3 3
C5 1 1 1 1 1 1 1 1 1 1 1 1
C6 1 1 1 1 1 1 1 1 1 1 1 1
C7 1.7 2.5 4.1 3.4 5 8.3 54.8 58.5 65.6 12.5 18.8 31.2
Riversoft 4 Riversoft 8 Riversoft 15 Riversoft 30
24.6 25.5 27.4 36.1 38.0 41.3 54.8 58.5 65.6 104.5 113.1 131.0
