SCREENLOGIC
®
INTERFACE Wireless Connection Kit Installation Guide
Technical Support
Sanford, North Carolina (8 A.M. to 4:30 P.M.)
Phone: (800) 831-7133
Fax: (919) 566-8920
Moorpark, California (8 A.M. to 4:30 P.M.)
Phone: (800) 831-7133 (Ext. 6502)
Fax: (805) 530-0194
Web sites: visit www.pentairpool.com and www.staritepool.com
Related manual: ScreenLogic
®
Interface User’s Guide (P/N 520493)
Contents
Overview ........................................................................................................... 1
Summary installation steps ............................................................................... 1
In this Installation Guide ................................................................................... 1
ScreenLogic Interface Wireless Connection Kit Contents ............................... 2
Step 1: Mount the Outdoor Wireless Transceiver and Connect to the
IntelliTouch or EasyTouch Load Center ........................................................... 3
Step 2: Connect the Indoor Wireless Transceiver to the ScreenLogic
Interface Protocol Adapter ................................................................................ 8
FCC Regulatory Safety Notice - This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• Modifications not expressly approved by the party responsible for FCC
compliance could void the user’s authority to operate the equipment.
In this Installation Guide
Use the information in this manual for installing the ScreenLogic
®
Interface
Wireless Connection kit contents.
• For ScreenLogic Interface system operating instructions, refer to
the ScreenLogic Interface User’s Guide (P/N 520493)
