Pepperl+Fuchs Absolute Rotary Encoder User Manual

Absolute Rotary Encoder
Programmable Parameters
2017-04
67
9.5.74 Object 6508h: Operating Time
This object indicates the operating time of the device. Currently the operating time is not
supported and the value of this object will always be FFFFFFFFh.
9.5.75 Object 6509h: Offset Value
This object contains the offset value. It is been calculated by the preset function and shifts the
physical position value with the desired value.
9.5.76 Object 6509h: Module identification
This object shall provide the manufacturer-specific offset value, the manufacturer-specific
minimum and maximum position value.
9.5.77 Object 650Bh: Serial Number
This object contains the serial number of the device. The serial number is also supported in
object 1018h subindex 4h.
MSB LSB
Software Version 4.4 Profile Version 3.2
Upper Software
Version
Lower Software
Version
Upper Profile Version Lower Profile Version
04 04 03 02
Subindex Description Data Type Default Value Access
Restore after
Boot up
0h Operating time Unsigned 32 FFFFFFFFh ro no
Ta b l e 9 . 9 0
Subindex Description Data Type Default Value Access
Restore after
Boot up
0h Offset value Integer 32 ro no
Ta b l e 9 . 9 1
Subindex Description Data Type Default Value Access
Restore after
Boot up
0h Highest supported
subindex
Integer 32 3 ro no
1h Manufacturer offset
value
Integer 32 ro no
2h Man. min. position
value
Integer 32 ro no
3h Man. max. position
value
Integer 32 ro no
Ta b l e 9 . 9 2
Subindex Description Data Type Default Value Access
Restore after
Boot up
0h Serial number Unsigned 32 see nameplate ro no
Ta b l e 9 . 9 3
