5. Specifications
22
5.3 Optics
5.4 Fluorescence Imaging Components
5.5 Environmental Requirements
Optical Component Specification
Lens f/stop f/1- f/8
Field of View (FOV) 3.9, 6.5, 13, 19.5, and 26 cm
Resolution >60 μm (FOV = 3.9, f/1)
Scanning Laser <1 mW at 532 nm
Fluorescence Imaging
Component
Specification
Excitation Filters 12 positions, 25 mm diameter, 10 filters supplied
Emission Filters 22 positions, 60 mm diameter, 18 filters supplied
Background
(Autofluorescence and
Leakage)
1 part in 10
7
typical
Lamp 150 W quartz halogen
21 V
3250° Kelvin
Environmental Component Specification
Temperature 15 -25° C (59-78° F)
Humidity 0-80% non-condensing
Type of Use Indoor
Sound Level 61 dB < 500 Hz
Stage Temperature Ambient to 40° C
Altitude Rating <2000 meters (6560 ft.)
